Products
Product Overview
RADX Technologies develops COTS, High-Performance Computing (HPC) hardware and software products that enable advanced signal processing, data acquisition, and ML/DL AI inference applications for SDR, Modular T&M, and EW markets.
As an NI Application Solution & Product Partner, RADX focuses on the Trifecta and Catalyst Family of PXIe/CPCIe Modules and Subsystems that complement the NI PXIe and USRP product line. All RADX PXIe modules are COTS products that are BAA and TAA compliant and available on GSA from TestMart.
PXIe-SSD Data Storage
COTS, Cost-Effective, High-Performance, Single-Slot, PXIe-SSDs that Use Data-Center 15mm NVMe U.2 SSDs
First PXIe-SSDs with 15mm G4/G5 Data Center NVMe U.2/U.3 SSDs from Micron, Flexxon, Phison, Seagate, Samsung and Sabrent. RADX Patent-Pending Venturi Technology for Accelerated SSD I/O. Ideal for Ultra-Wideband PXIe Apps: RF & IF, DSO, ADC & Video Capture, Record, Playback & Analysis.
Key Features
- Up to 61.44 TB (UF) per Slot
- Low Power: < 38W TDP (ANY PXIe)
- Industry-Leading Sustained, Seq. Read & Write Perf — Up to ~7.1 GB/Sec in G3 x8 for U.2 Configs
- SW RAID via 2+ Modules for ~2x Enhanced Perf or Reliability
- U.2 Unmatched Write Endurance — 14.0 PBW to 140.1 PBW
- Extreme Endurance (EE) Options for Circular Buffer Apps
- Industry Leading Price / Performance (TB/$k and PBW/$k)
- Rapid Delivery: ~30 to ~60 Day ARO, based on SSD Avail.
Products in This Family
PXIe-GPU Compute & Graphics
Easy-to-Program, High-Performance, Cost-Effective, COTS, Single-Slot PXIe-GPUs with NVIDIA® RTX GPUs with 1.0 to 91.1 FP32 TFLOPS Compute Acceleration
Eliminates the Need for External GPU Servers. Reduces or Eliminates FPGA Development Hassles. NVIDIA RTX-based PXIe-GPUs and PXIe-eGPUs with 1.0 to 91.1 FP32 TFLOPS for GPU-Accelerated AI (ML/DL/LLM), Image, Video, Graphics & Digital Signal Processing.
Key Features
- NVIDIA RTX-based PXIe-GPUs and PXIe-eGPUs with 1.0 to 91.1 FP32 TFLOPS
- 4x to 200x Faster FP32 Compute Performance versus CPUs and FPGAs
- Support for up to 256M Point FFTs and 1B FFTs/Sec — well beyond FPGA Limits — for Industry-Best RBW, 100% POI and LPI Signal Detection & Classification
- NVIDIA NVENC / NVDEC Real-Time Video CODECs for 2K/4K/8K Video Comp/Decomp
- Support for RT-Linux & nvCOMP via G2CPU
- Easy-to-Program via LabVIEW / G2CPU, MATLAB, Python & C/C++ with optimized support for popular Compute & AI Frameworks & Libraries
- Rapid Delivery: ~30 to ~60 Day ARO Lead-Time
- Support for Windows and Linux
Products in This Family
PXIe-GbE Networking
COTS Single-Slot PXIe/CPCIe High-Performance Ethernet NIC Modules
Catalyst PXIe-GbE™ PXIe HPC Ethernet NIC Modules are COTS, single-slot PXIe/CPCIe 4×10, 2×25 & 2×100 GbE NICs. Based on Intel® and NVIDIA® Mellanox® PCIe NICs, Catalyst PXIe-GbE provides industry-leading networking performance, pricing & value for PXIe systems with rapid (~30 to ~45 day) delivery.
Key Features
- Based on Intel® and NVIDIA® Mellanox® PCIe NICs
- Single-slot PXIe/CPCIe form factor
- Industry-leading networking performance and value
- 4×10, 2×25 & 2×100 GbE configurations available
- Rapid ~30 to ~45-day delivery for small volumes
Products in This Family
PXIe-USB Connectivity
COTS PXIe/CPCIe High-Speed USB-C Connectivity Modules
The RADX Catalyst PXIe-USB brings 4× USB 3.2 Gen 2×2 (20 Gbps) USB-C ports to PXIe and CPCIe systems via the HighPoint RU1444C controller. Designed for data-intensive T&M, EW, and data acquisition applications requiring high-bandwidth USB peripheral connectivity directly within the PXIe chassis.
Key Features
- 4x USB 3.2 Gen 2×2 (20 Gbps) USB-C ports via the HighPoint RU1444C controller
- Single-slot PXIe/CPCIe form factor; PCIe Gen 3 ×4 host interface
- 7.5 W per-port power delivery for bus-powered peripherals
- Windows 10/11 and Linux driver support
- BAA and TAA compliant, Designed and Assembled in the USA
- Available on GSA via TestMart
Products in This Family
Looking for current pricing across all RADX PXIe modules?
View Full Price ListBAA / TAA Compliant. GSA Available.
All RADX PXIe modules are COTS products that are designed and assembled in the USA and available on GSA from TestMart.
